ALL ROAD PLEASURE.
The new NYTRO GRINTA is pure freedom. Gravel has wonderfully expanded the possibilities of traveling on roads that were not even contemplated by road cyclists until yesterday. With NYTRO GRINTA you can go even further thanks to the thrust of its Fazua Evation engine able to support you to overcome the obstacles between you and the fun!
The Fazua Motor offers three levels of assistance:
Breeze:
A gentle, constant and 100 watts strong tailwind even at low rider power
River:
Progressive and very sporty mode, for a smooth riding experience. The strength of the support precisely follows your foot and your own power. Give a lot - and get a lot from the motor (max. 210 watts)
Rocket:
Aggressive assistance that helps you to tackle the steepest sections even with moderate driver power (max. 250 watts)
ALUMINIUM 6061 TRIPLE BUTTED
Aluminum-cast frames engineered to deliver high level of durability, torsional rigidity and a granted long lifespan.
ACTIVE GEOMETRY
Easy and comfortable position for all riding styles, allowing riders to sit comfortably and enjoy the ride.
CE | 440 | 500 | 550 | 590 |
---|---|---|---|---|
CC | 440 | 500 | 550 | 590 |
L | 540 | 555 | 575 | 590 |
A [°] | 74 | 74 | 73.5 | 73.5 |
B [°] | 70.5 | 71 | 71.5 | 72 |
P | 435 | 435 | 435 | 435 |
T | 138 | 159 | 181 | 202 |
D | 75 | 75 | 75 | 75 |
R | 45 | 45 | 45 | 45 |
G | 395 | 395 | 395 | 395 |
REACH | 369 | 381 | 392 | 402 |
STACK | 563 | 585 | 608 | 630 |
CE: SEAT TUBE CENTER - END, CC: SEAT TUBE CENTER - CENTER, L: TOP TUBE CENTER - CENTER, A[°]: SEAT TUBE ANGLE, B[°]: HEADTUBE ANGLE, P: CHAINSTAY, T: HEADTUBE, D: BB DROP, R: FORK RAKE , G: FORK HEIGHT, REACH, STACK
Specs
Frame | Aluminium 6061, triple butted with integrated battery and cable routing, 12x142 thru-axle |
---|---|
Fork | nytro carbon fork , tapered head tube |
Wheels | Shimano RS |
Axles | Pinarello Axle 12x100 & 12x142, tool free removal |
Tires | Maxxis Rambler 700x40c |
Bottom Bracket | Fazua Bottom Bracket |
Crankset | Most custom chainrings |
Chainrings | Most custom chainrings |
Shifters | SRAM Apex |
Rear Derailleur | SRAM Apex 1 sgs 11s 1x |
Cassette/Freewheel | SRAM Apex |
Chain | SRAM PC1110 |
Brakes | SRAM Apex 2 Piston |
Rotors | 160mm rotor |
Handlebars | Jaguar XA Aero Di2 |
Tape/Grips | Bar Tape MOST Ultragrip evo 3mm - Black |
Stem | Tiger Alu Aero Di2 |
Seatpost | Most Alu Round Seatpost |
Saddle | Most Lynx Aircross FEC Alloy Large 145mm |
Pedals | Sold separately |
Motor | Fazua Evation Ride 50 |
Battery | Fazua Evation 1.0 250Wh |
* Subject to change without notice.
Part Numbers
Option | MPN | Store SKU |
---|---|---|
Petrol / Small | PB-21-GRNT-SM-GR-A11 | |
Petrol / Medium | PB-21-GRNT-MD-GR-A11 | 210000028707 |
Petrol / Large | PB-21-GRNT-LG-GR-A11 | |
Petrol / X-Large | PB-21-GRNT-XL-GR-A11 |
